-220V(110/220V) MMA MAG MIG TIG 4-IN-1 IGBT INVERTER WELDER
-Anti-Stick/Hot-Start/Arc Froce for MMA
-Inductance Regulation for MIG/MAG
-Quick Arc-Start,Quick Wire Feed for MIG/MAG Welding
-Lift DC TIG
4-IN-1
-Solid Wire welding
-Flux cored wire welding
-Electrode welding
-Argon Tungsten welding
4-IN-1
-Solid Wire welding
-Flux cored wire welding
-Electrode welding
-Argon Tungsten welding
Inbuilt Advanced Function for MMA welding
- ANTI-STICK is available
- HOT-START is available
- ARC-FORCE is available
Inductance Regulation for MIG/MAG welding
- A. Adjust the welding softness for satisfying the user’s welding habit.
- B. Adjust the penetration, ensure the adhesion of the weld bead, realize the consistent penetration of the workpiece, and improve the welding quality of the
workpiece
Quick ARC-START and Wave Control
for MIG/MAG welding
Stabilized the small current transition, Reduce the splash of large current by 70% ~ 80%,The constant current arc starting improves the arc starting to 100%. Adopt analog circuit high-speed and accurate control technology, to achieve precise control of each droplet transfer and high-speed welding. High penetration rate and excellent weld bridging ability, realize the wide gap welding and high weld quality. Ultra-low heat input can control the formation of weld and minimize the deformation.
Poweful wire feeder driven by 45Watt electric motor, and it supplies high effeciency and stable feeding speed, up to 15m/min.
Quick Select Drive roll help you setup quickly by offering grooves for solid wire and flux-cored wire.
Smooth-start provides a smooth, spatter-free arc starting.
Thermal Overload Protection shuts down unit and activates over temperature light if airflow is blocked or duty cycle is exceeded.Automatically resets when it cools.
Uses 100 or 200mm spools for different demands.
Spoolgun is optional function that allows the simple connection of Spoolgun for the use of thin or softer wires that don’t have the column strength to feed through standard MIG
torches,such as aluminium wire.
| Model | NEOMIG-160(BV) |
| Type | IGBT INVERTER TECHNOLOGY, FULL-BRIDGE |
| Input Voltage | Single Phase AC~110V and/or AC~230V |
| Frequency | 50/60Hz |
| Input Power | 4.5kW |
| Output Current Range @230V (MIG) | 20~160 AMP |
| Output Current Range @230V (MMA\TIG) | 20~140 AMP |
| Output Current Range @110V (MIG\MMA\TIG) | 20~125 AMP |
| Open Circle Voltage | 60V |
| Duty Cycle | 100% @ 108A/125A | 60% @ 160A |
| m\min | 15 |
| Wair Dia. | 0.6~1.2mm |
| Reel Dia./KG | 100mm 1KG/200mm 5KG |
| Effenciency | 85% |
| Class of Insulation | F |
| Shell Protection Grade | IP21 |
| Welding Capability of Electrode | 1.6mm ~ 3.2mm |
| N.W. / G.W. | 14kg / 18kg (with all accessories) |
| Machine Dimensions | 520*320*400mm |
| Packaging | Brown Carton or Color Box |
| Carton Size | 640*320*480mm |
